1. System Overview
1.1 Seitz 6x17 Digital
1
2
3
4
5
6
Camera body
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Lens
Lens tube
Lens adaptor*
Lens brackets
Viewfinder
Viewfinder release
Shift wheel
Hand grips
Release + on button
Tripod mount
Attachment for neck strap
Ethernet socket
Power socket
Loading gate brackets
Brackets to attach compact
computer
Loading gate
Digital scan back
Power cable/connector
Ethernet cable/connector
Battery + battery charger
socket
1
2 3 4 5
5
6
7
9 9
10
8
11
12
12
15
15
17
13 14
18
19
20
16
16
21
* For Linhof 617 and Fuji 617 lenses
