SRL2
11
English
6. Slide the left and right clips into their corresponding sides
between the external shell and the inner shell.
7. Reattach the internal paddings beginning with the rear and click
the snap fasteners.
8. Lower the face cover completely.
2. Facing the USB port on the Bluetooth module toward the rear of
the helmet, push the module into the corresponding slot until you
hear a click.
3. Insert the helmet speakers and the microphone into the grooves
in the inner shell of the helmet.
4. Slide the antenna into the corresponding place. Make sure that
the grooves under the antenna t the corresponding grooves.
5. Repeat the process on the other side to install the button module.
