ADN Digital Conference System |27
Overview of the components
ADN-W CASE UNITS charging case
Overview of the status LEDs The status display for charging process is identical with the status display of the
ADN-W L 10 charger (see page 25).
ADN-W CASE BASE
Cas
e lid
Case bottom
Charging compartments for 10 wireless
conference units with their ADN-W BA
battery packs
Button for charge status indication
Operation indicator, green
Status display for charging process
Fans
Mains fuse
Mains socket
On/off switch
Carrying handles, foldable
Type plate and hazard
warnings
Butterfly locks
3
4
2
9
6
7
8
5
A
1
A
A
9
9
9
5
<
ADN-W CASE UNITS
MADE IN GERMANY
Art.-No.: 504956 Ser.-No.: XXXXXXXXXX
~100-240V, 50/60Hz Max. Power Consumption: 250 W
15
CAUTION / AVIS
RISK OF ELECTRIC SHOCK - DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR
1
2
3
4
5
6
7
8
9
<
A
1
1
1
1
Butterfly locks
Wheels
Lockable casters
1
1
3
1
2
3
1
2
1
2
3
