ADN Digital Conference System |87
Configuring the conference system via the central unit
“Conference Recording” menu
“Record” Starts/stops the audio recording of the conference
channels on a USB mass storage device
“On”/“Off” 101
“Recording Status” Provides information on the status of the audio
recording and on the available memory space on
the USB mass storage device
“Wireless Menu”
“Country” Country/area settings for radio communication “Europa”, “USA/Canada”,
“Mexico”, ...
95
“Channel Selection” Adjusts the channel selection mode “Automatic”/“Manual” 96
“Access Mode” Adjusts the connection mode for wireless
conference units
“Open”/“Closed” 96
“Switch Off Wireless Units” Switches off all connected wireless conference
units
“Yes”/“No” 96
“System Menu”
“Units” Displays the type and number of the conference
units connected to the ADN CU1 central unit or
ADN PS power supplies or connected wirelessly to
an ADN-W AM antenna module
105
“Topology” Displays the type of topology connected to the
ADN PS power supplies (simple cabling or
redundant ring topology )
106
“Diagnostics” Calls up the “Diagnostics” submenu – 107
“Versions” Calls up the “Versions” submenu – 111
“Diagnostics” menu
“System Load” Provides information on the current supply (A),
voltage supply (V) and power (P)
107
“Temperature” Provides information on the temperature status 108
“Bus Statistics” Provides information on the status of data trans-
mission/errors
109
“Start Self-Test” Performs a self-test on the conference system “Yes”/“No“ 110
“Reset Break Indication” Resets the error counter (“Break Counter”) in the
“Bus Statistics” menu item
“Yes”/“No” 110
“Reset Error Indication” Resets the display for data bus errors (“Error
Indication”) in the “Bus Statistics” menu item
“Yes”/“No” 111
Display Function of the menu item
Option/display page
Recording Status
No
Status : Off
Free Space : 200 GB
Units
No
System : 216 D1 06 C1
CU : 00 D1 04 C1
PS01 : 29 D1 01 C1
Topology
No
PS01.I.1 :
PS01.I.2 : – –
PS01.II :
System Load
No
CU.I : – – A V
PS07.II.1 : A – – V
PS07 : P
Temperature
No
CU :
PS07 :
PS11 :
Bus Statistics
No
Error Indication : ☺
Break Counter : 1
To Next Page
