SENSAPHONE 400 User’s Manual
5.1.1 programmIng Zone ConFIguratIon
1. Press STANDBY to place the Model 400 in Standby mode.
RUN
STANDBY
2. Wire sensors to the zones to the back of the Model 400 (see Chapter 2,
Section 2.10).
3. Press RUN. The red light glows when the Model 400 returns to Run
mode.
RUN
STANDBY
4. Press SET.
SET
5. Press CONFIG.
CONFIG
6. The Model 400 audibly recites the configuration for each of the four
zones:
• If the zone is open, the Model 400 recites the number of the zone and says
“normally open.”
• If the zone is closed, the Model 400 recites the number of the zone, and
says “normally closed.”
• If the zone is configured as temperature, the Model 400 recites the num-
ber of the zone, followed by “Temperature.”
5.1.2 InterrogatIng Zone ConFIguratIon
1. Press WHAT IS.
WHAT
IS
2. Press CONFIG.
CONFIG
The Model 400 will audibly recite the configuration of each zone.
