SensorTherm METIS M3 series User Manual

METIS M308 / M309 / M313 / M316 / M318 / M323 / H309 / H316 / H318 (12-pin)
Communication via Serial Interface / Interface Commands
63
Bit 4 = 1 Marker appears Bit 10 = Auto exposure
Bit 5 = US Format Bit 11 = Auto white balance
ot
X
Show / hide time
X=0...1; 0=Hide time; 1=Show time
ot
otus
HHMMSS
Set time (6-digit ASCII), otus=US time)
HH = hour, MM = minute, SS = second
ov
X
Show / hide temperature
X=0...1; 0=Hide temperature; 1=Show temperature
ox
TT...TT
Write own user text: TT...TT= Text (max. 16 ASCII characters)
vb
XX
White balance / automatic white balance
XX=0x00...64 (= 0...100% of the window area, calculated centric to the image cen-
ter) or ff (= automatic white balance)
vc
XX
Color saturation
XX=0x00…ff (= Level 0-255)
vd
(only M3)
X
Camera module (power) on/off
X=0...1; 0=off; 1=on
vh
XX
Definition of the image
XX=0x00…ff (= Level 0-255)
vi (vh)
XX
Brightness (AEC)
XX=0x00…ff (= Level 0-255)
vm
X
Color transmission system camera module: X=0...1; 0=NTSC; 1=PAL
vq
X
Image setting color / monochrome: X=0,1; 0=color picture; 1=monochrome image
vt (vm)
X
Test image: X=0, 1; 0=Normal image; 1=Test image
In addition, for devices with built-in motorized focus
moa
XXXX
Measuring distance XXXX in mm (is rounded up or down in 10 mm resolution!)
In addition, for devices with Profibus
fpa
XX
Fieldbus address: 00..7fh
fbm
Fieldbus mode (00, 01, 02)
Mode 0 = old Profibus mode
(as formerly MS09 / MQ11, depending on the device)
Mode 1 = new M3 format (default, like fbx-codes)
Mode 2 = flexible format (see fbd codes)
fbr
Reset fieldbus (always apply if format change)
fbd
XXXXXX32x
Fieldbus codes 32 bytes of data 32xYY (for mode 2)
fbd
XXYY
Write fieldbus byte YY (address: XX = 00.1fh) (for mode 2)
fbx
Read fieldbus codes 32 bytes of data 32xYY (default for mode 1)
Old commands: to standardize the command structure, some old commands with numeric parameters are replaced with new
ones with hexadecimal coded. The old commands still work, but should no longer used in reprogramming:
ms (Read temperature value, 5-digit. dec.)  mw
ez (Response time, 1-digit. dec.)  et
lz (Max. value, 1-digit. dec.)  lm in combination with lt
em (Emissivity, 2-digit. dec.)  eg1
gt (Device temperature, 2-digit. dec.)  ts
