Page #48 background imageLoading...
Page #48 background image
METIS M308 / M309 / M313 / M316 / M318 / M323 / H309 / H316 / H318 (12-pin)
SensorTools Software
48
Mode 2 (Data packet size 64 Byte): available and freely selectable pyrometer data
Length
Bytes
Meaning
2
Measured temperature (in 1/10 degree)
2
2-color temperature (in 1/10 degree)
2
Temperature channel 1 (in 1/10 degree)
2
Temperature channel 2 (in 1/10 degree)
2
Temperature sum channel (in 1/10 degree)
2
Flame temperature (in 1/10 degree)
2
Emissivity slope (in 1/10 degree)
2
Emissivity channel 1 (50…1200)
2
Emissivity channel 2 (50…1200)
2
Emissivity sum channel (50…1200)
2
Transmittance channel 1 (50…1000)
2
Transmittance channel 2 (50…1000)
2
Transmittance sum channel (50…1000)
2
Fill factor channel 1 (50…1000)
2
Fill factor channel 2 (50…1000)
2
Fill factor sum channel (50…1000)
2
Switch-off level (20...900)
2
Soot factor (50…250) (Flame)
2
Optical density (0...10000) (Flame)
2
Storage mode (0...4)
4
Clear time (0…250000, 0...25 s)
4
Response time (0…100000, 0...10 s)
2
Analog output 1+2
2
Error status (0...255)
2
Internal device temperature (00...100, in 1°C)
2
Int. device temp. (00…25600, in 1/256°C)
2
Detector temperature (00...100, in 1°C)
2
Detector temperature (00…25600, in 1/256°C)
2
Beginning of device temp. range (in degree)
2
End of device temp. range (in degree)
2
Beginning of temperature sub range analog 1
(in degree)
Length
Bytes
Meaning
2
End of of temptemperature sub range
analog analog 1 (in degree)
2
Beginning of temperature sub range
analog 2 (in degree)
2
End of of temptemperature sub range
analog analog 2 (in degree)
2
Devices with controller:
Setpoint value (in 1/10 Grad)
2
Devices with controller:
Proportional band Xp (0…10000) in 0.1%
2
Devices with controller: Integral time Ti
(0…65535) Factor × sampling time
2
Devices with controller: Derivative time
Td (0…65535) Factor × sampling time
2
Devices with controller: Minimum control-
ler output power P-Min (0…999) in 0.1%
2
Devices with controller: Maximum control-
ler output power P-Max (0…999) in 0.1%
2
Devices with controller: AutoTune target
temperature (0…1000) in 0.1%
2
Devices with controller: Controller power
limitation P dynamik (0…10000) in 0.01%
2
Devices with controller:
Ramp time (0…65535) in 100 ms
2
Devices with controller:
Hold time (0…65535) in 100 ms
2
Devices with controller:
Sampling time (100...2500) in 10 µs
2
Devices with motorized optics: smallest
possible measuring distance (in mm)
2
Devices with motorized optics: largest
possible measuring distance(in mm)
2
Devices with motorized optics: Current
set measuring distance (in mm)
-
End mark
7.2.5.2 Writing Pyrometer Data
To write parameters to the pyrometer, the same interface commands are used (see 11) as used on the
RS232 / 485 serial interface.
Byte assignment (16 Byte):
The first 15 bytes contain the interface command (in ASCII, without the device address) + <CR>
The 16th byte is set to:
- 03h (the command is sent to the pyrometer, the pyrometer responds with ok + <CR>, which means
that the command was accepted. This answer is on the output as long as the byte is at 03h. Py-
rometer data will no longer be displayed and refreshed during this time!)
- 01h (the command is sent to the pyrometer, there is no response from the pyrometer)
- 00h is used to reset of receiving the selected data packet.
Example: la1 + <CR> (switch on laser targeting light, also see 11, Interface commands la)
Byte
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Command
l
a
1
<CR>
*
*
*
*
*
*
*
*
*
*
*
01h
ASCII
6Ch
61h
31h
0dh
*
*
*
*
*
*
*
*
*
*
*
01h
* filled with 00, not relevant
