SensorTherm METIS M3 series User Manual

METIS M308 / M309 / M313 / M316 / M318 / M323 / H309 / H316 / H318 (12-pin)
Technical Data
54
Common Data
Temp. sub ranges
Any range adjustable within the temperature range (minimum span 50°C)
Emissivity ε
0.050–1.200 (corresponds 5–120% in 0.1% steps)
Transmission
0.050–1.000
Fill factor spot size
0.050–1.000
Analog output signal
2 programmable analog outputs 0 or 4–20 mA, switchable, max. load: 500 Ω
Resolution 0.0015% of the adjusted temperature sub range (16 Bit).
User selectable: Measuring temperature, device temperature or control output (if
equipped with a controller).
Outputs can be set individually, inside or outside the measuring range.
3 configurable
Inputs / outputs
 Digital inputs (max. 3 inputs, protected against reverse polarity): laser targeting light
on/off, clearing of peak picker, controller start (when equipped with PID controller),
load pyrometer configuration, trigger input for start / stop of measured value record-
ing.
 Digital outputs (max. 3 outputs, max. 50 mA, protected against short circuit): limit
switch, exceeding the beginning of temperature range (for material recognition), de-
vice ready after self-test, device over-temperature. When equipped with PID con-
troller: controller active, control process within limits, control process finished.
 Analog input (0–20 mA, protected against reverse polarity and incorrect connec-
tion): analog adjustment of the emissivity, measuring distance at motor focus or
setpoint for PID controller (when equipped with PID controller).
Maximum value stor-
age / Peak picker
Automatic hold mode (built-in double storage) or manual time settings to clear or ex-
ternal clear (via configurable input)
Display
10-digit LED display (5 mm high) for temperature display or device settings
Resolution 0.1°C or 0.1°F
Parameter settings
Push buttons on the device, serial interface, PC software
SensorTools
or via self-
compiled communication program: Emissivity, transmission, fill factor, temperature sub
range, settings for peak picker, device address, baud rate, response time, selecting
analog outputs 0/4–20 mA, interface RS232/RS485 (selection on the device only),
°C/°F, language (English / German), measuring distance at motorized focus optics.
Power supply
24 V DC (18–30 V DC), protected against reverse polarity
Isolation
Voltage supply, analog and digital output are galvanically isolated from each other
Sightings
(optional)
 Through lens sighting with adjustable attenuation filter for eye protection of bright
targets
 Laser targeting light (red, λ=650 nm, P< 1 mW, class II to IEC 60825-1)
 Color CCD camera, field of view: ca. 3.6 x 2.7% of measuring distance
output signal: FBAS signal ca. 1 V
PP
, 75 Ω, CCIR, NTSC / PAL switchable,
resolution: NTSC: 720 x 480 pixel; PAL: 720 x 576 pixel
frame rate: NTSC: 60 Hz, PAL: 50 Hz
Storage temperature
-20 to 85°C (-4 to 185°F)
Relative humidity
Non-condensing conditions
Housing / protection
class
Aluminum, IP65 according to DIN 40 050 with connector
Weight
650 g
CE label
According to EU directives for electromagnetic immunity
9.1 Storage
Store packages under the following conditions:
 Do not store outdoors
 Store dry and dust-free
 Do not exposed to corrosive media
 Protect from direct sunlight
 Avoid mechanical vibrations
 Storage temperature: -20 to 85°C
 Relative humidity: max. 95%,
no condensing conditions
