METIS M308 / M309 / M313 / M316 / M318 / M323 / H309 / H316 / H318 (12-pin)
Technical Data
56
9.3 Composition of the Type Number
The equipment version of the pyrometer is encoded in the 22-digit model number as follows
(Example type number M309 with 7502500°C; laser targeting light, motorized focus, optics):
Digit
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
Expl.:
M
3
0
9
0
7
5
0
2
5
0
0
0
5
8
1
3
0
4
2
3
A
Digit
Indication of the various points
Code
Meaning / Example
01-02
Series M3
M3
Metis M3
Series H3
H3
Metis H3
03-04
Spectral range
08
0.855 0.905 µm
09
0.71.1 µm or 0.87 µm (Si)
13
1.27 µm (InGaS)
16
1.451.8 µm or 1.4 µm (InGaS)
18
1.652.1 µm (InGaS)
23
22.6 µm (InGaS)
05-08
Beginning of temperature range [°C]
0750
750°C
09-12
End of temperature range [°C]
2500
2500°C
13
Sighting
1
Laser targeting light
2
View finder
4
Color camera module
14
Serial interface
2
RS485
5
RS232 / RS485 (switchable)
3
Profinet integrated
4
Profibus integrated
15
Lens type
1
Fixed focus lens
2
Focusable optics
3
Fiber optics 0.2 mm Ø with focusable optics
4
Fiber optics 0.4 mm Ø with focusable optics
8
Motorized focus
7
Focusable optics (only M323)
B
Heavy duty stainless steel sensor head
for 0.2 mm fiber with OL25
C
Heavy duty stainless steel sensor head
for 0.4 mm fiber with OL25
16-17
Minimum response time
13
<1 ms
41
<40 µs
18
Configuration
0
Standard (12 pin connector, display, push
buttons, 3 digital inputs / outputs)
4
Standard + PID controller
19
Digital display
4
With display (12 pin connector)
20
Analog outputs
2
2 analog outputs
21
Digital input / digital output
3
3 digital inputs / outputs / 1 analog input
020 mA (with 12 pin connector)
22
Measuring distance / Optics
A
Optics A (depending on digit 15:
integrated optics or fiber optics)
B
Optics B
C
Optics C
D
Optics D
G
Optical fiber optics G
H
Optical fiber optics H
