SensorTherm METIS M3 series User Manual

METIS M308 / M309 / M313 / M316 / M318 / M323 / H309 / H316 / H318 (12-pin)
Technical Data
57
9.4 Accessories
Ref. number
Meaning
AL11-XX
1)
Connection cable with right angled connector
AL43-XX
1)
Connection cable with straight connector
AL17- XX
1)
Connection cable with right angled connector + 0.5 m SC10 cable
AM11-XX
1)
Connection cable with right angled connector + 1 m interface cable with SUB-D plug
AM43-XX
1)
Connection cable with straight connector + 1 m interface cable with SUB-D plug
AM17- XX
1)
Connection cable with right angled connector + 0.5 m SC10 cable + 1 m interface cable with
SUB-D plug
AU11-XX
1)
Connection cable with right angled connector + RS232USB interface converter
AU43-XX
1)
Connection cable with straight connector + RS232USB interface converter
AU17- XX
1)
Connection cable with right angled connector + 0.5 m SC10 cable
+ RS232USB- interface converter
AV11-XX
1)
Connection cable with right angled connector + RS485USB interface converter
AV43-XX
1)
Connection cable with straight connector + RS485USB interface converter
AV17- XX
1)
Connection cable with right angled connector + 0.5 m SC10 cable
+ RS485USB interface converter
AK50-XX
1)
Connection cable for camera models
DK5485
Interface converter RS485USB, 1.7 m cable, open wire ends
DK4000
Interface converter RS485USB, 1.7 m cable, 9-pin Sub-D-connector
DK5232
Interface converter RS232USB, 1.7 m cable, open wire ends
DK3000
Interface converter RS232USB, 1.7 m cable, 9-pin Sub-D-connector
AK72-XX
2)
Profibus input connection cable (straight female connector and connection wires)
AK73-XX
2)
Profibus output connection cable (straight male connector and connection wires)
AK76-XX
2)
Profibus input / output connection cable (straight male and female connectors)
for connecting 2 Profibus devices
AK81-00
Profibus terminating resistor with male connector M12 x 1
AK54-XX
1)
Profinet connection cable
NG12-00
Din-rail power supply 24 V DC, 1.6 A
NG15-00
Desktop power supply 24 V DC, 2.5 A
IF00-00
LED digital indicator for panel mounting
Regulus RD
PID program controller as bench top model
Regulus RF
PID program controller for panel mounting
KG10-00
Cooling jacket to 200°C ambient temperature
KG20-00
Cooling plate for devices with focusable lens
KG31-00
Cooling cap for devices with focusable lens
BL10-00
Air purge accessory for devices with fixed focus optics
BL11-00
Air purge accessory for devices with focusable optics
BL13-00
Air purge accessory for fibre optic cable lens assembly OL12
BL14-00
Air purge accessory for fibre optic cable lens assembly OL25
HA10-00
Mounting bracket
HA15-00
Adjustable mounting bracket for fibre optics OL12
HA14-00
Adjustable mounting bracket for fibre optics OL25
HA20-00
Swivel mounting base
HA21-00
Swivel mounting base for Metis with SC10 scan adapter
HA22-00
Swivel mounting base for cooling jacket
SC10-41
Scan adapter
SC11-01
Line scanner, digital, programmable
SC12-01
Line scanner, programmable via internal keyboard and digital display
1)
XX Specify length in meters (available in 5 m steps)
1)
XX Specify length in meters (XX= 2, 5, 10, 15 m)
