METIS M308 / M309 / M313 / M316 / M318 / M323 / H309 / H316 / H318 (12-pin)
Technical Data
53
9 Technical Data
Device-specific M3
Model
M308
M309
M313
M316
M318
M323
Temperature ranges
[°C]
6001400
7001800
5501400
6001600
6501800
7502500
9003000 *
)
10003300 *
)
4001400
4501800
5002200
5002600
5503000
6003500
2001300
2501300
3501800
4002500
5003300 **
)
100700
1501200
1801300
50800
801200
1001500
Spectral range [µm]
0.855
0.905
0.71.1
*
)
0.87
1.27
1.451.8
**
)
1.4
1.652.1
2 2.6
Detector
Silicon
Silicon
InGaAs
InGaAs
InGaAs
InGaAs
Response time t
90
< 1 ms (with dynamical adaptation at low signal levels), adjustable up to 10 s
Exposure time
< 0.5 ms
Uncertainty
(ε = 1, t
90
= 1s, T
A
= 23°C)
Full-scale temp. up to 2500°C: 0.25% of reading in °C+1K
Full-scale temp. above 2500°C: 0.5% of reading in °C
0.4% of reading in °C+1K
or 2°C (the higher value
is valid)
Note: The measurement uncertainty is reached after a warm-up phase of min. 5
minutes (device must be connected to the power supply)
Repeatability
(ε = 1, t
90
= 1s, T
A
= 23°C)
0.1% of reading in °C + 1 K
0,2% of reading in °C+1K
or 1.6°C (the higher value
is valid)
Temperature coefficient
(deviations to 23°C)
From 10 to 60°C: 0.02%/K
From 0 to 10°C and 60 to 80°C: 0.04%/K
10 to 60°C:
0.02%/K
0 to 10°C:
0.04%/K
070°C:
0.04%/K
Serial interface
RS232 (max. 115.2 kBd) or RS485 (max. 921.6 kBd), switchable.
Resolution 0.1°C or 0.1°F
Optics (optional)
Manual focusable or optional motorized focus or fixed focus optics
Power consumption
max. 6 VA (all outputs unconnected)
Ambient temperature
0 to 80°C, fiber optic and optics on optics side: -20 to 250°C (-4 to 482°F)
070°C
Note: To prevent its overheating, the laser targeting light is deactivated at a device
temperature from 65°C, the camera module from 55°C
Device-specific H3
Model
H309
H316
H318
Temperature ranges
[°C]
550 1200
600 1400
650 1600
750 1800
750 2000
250 800
300 900
350 1100
400 1200
500 1600
600 1800
700 2500
120 520
180 800
Spectral range [µm]
0.71.1
1.451.8
1.652.1
Detector
Silicon
InGaAs
InGaAs
Response time t
90
< 40 µs, adjustable up to 10 s
Exposure time
< 20 µs
Uncertainty
(ε = 1, t
90
= 1s, T
A
= 23°C)
0.5% of reading in °C + 1K
Repeatability
(ε = 1, t
90
= 1s, T
A
= 23°C)
0.2% of reading in °C + 1 K
Serial interface
RS485 (max. 921.6 kBd), resolution 0.1°C or 0.1°F
Optics (optional)
Manual focusable optics (built-in or as fiber optics version)
Power consumption
max. 12 VA (all outputs unconnected)
Ambient temperature
0 to 65°C (32 to 149°F), fiber optic and optics on optics side: -20 to 250°C (-4 to
482°F)
Note: To prevent its overheating, the laser targeting light is deactivated at a device
temperature from 60°C
