Sensus iPerl Technical Manual

Reporting 4-3
iPERL Water Management System Technical Manual WRMTM-40001
4.3 Printing Reports
To print an iPERL system report from the Unipro application:
1. From the Main screen, click the Reports menu option.
The Reports screen appears, as shown in Figure 4-1.
2. Choose a report to view from the Available Reports dropdown box.
3. Click the Open File button.
A Dialog Box appears, listing the stored reports. The reports are listed by the programmable ID and
the date/time that the report was stored. For example, a data log listed as
06230138_2007112680834 opens a report for meter ID 06230138 stored on 11/26/2007 at 8:08:34
a.m.
4. Choose the appropriate report.
5. Click the Open button.
The report will appear in the Unipro application.
6. Click the Page Setup... button to view the printing parameters.
7. Click the OK button.
8. Click the Print... button to print the report.

Sensus iPerl Specifications

General

Type	Ultrasonic water meter
Measurement Technology	Ultrasonic
Protection Class	IP68
Material	Composite
Pressure Rating	232 psi (16 bar)
Communication	AMR/AMI Compatible
Battery Life	20 years
Maximum Pressure	16 bar
Output	Pulse
Power Supply	Battery
Temperature Range	Up to 158°F (70°C)
Operating Temperature	32°F to 158°F (0°C to 70°C)
