Logs 5-5
iPERL Water Management System Technical Manual WRMTM-40001
5.5 Viewing Alarm Data
To view system alarm data:
1. From the Main screen, click the Data menu option.
2. Click the Alarms tab.
The Alarms screen appears, as shown in Figure 5-4.
Figure 5-4: Alarms Screen
3. Click the Read Meter button.
The alarm data will appear. Table 5-2 describes the different alarm data types.
Table 5-2: Alarm Data Types
Alarm Data Type Definition
Report Defines which alarms are to be tracked.
Active Alarms that are currently triggered.
Saved Alarms that have occurred within the persistence time since
the last unidirectional read. In other words, if an empty pipe
occurs, this alarm is latched until the next read, then remains
for a period of time until which the alarm flag is cleared.
