R301 RF POWER SUPPLY OPERATOR’S MANUAL
Note: the RFON* signal is edge triggered. A transition from a TTL
“high” to TTL “low” logic state must occur to enable the RF output. This
prevents accidental enabling of the RF output when the RF power supply
is powered-up in the ANALOG control mode or when the external
interlock (INTERLOCK) is re-established after an external system
interlock event.
8. Adjust the setpoint voltage as required.
9. Disable the RF Output. Open the connection between Analog Interface Connector pin 3
to pin 16 or apply a TTL logic “High” signal to pin 2.
!
Page 17
Seren IPS Inc.
6100130000 Rev. 0.05
