R301 RF POWER SUPPLY OPERATOR’S MANUAL
Installation:
Recommended mounting:
The R301 RF Power Supply is designed for placement on a tabletop or on a shelf within an
equipment rack, with another ½ Rack 3U piece of equipment, in a clean environment. The
table or equipment rack must be capable of supporting the full weight of the unit.
The R301 RF Power Supply is supplied with ½-Rack Mounting Ears. The mounting ears
are designed for securing the R301 to the equipment rack rail. The ½-rack mounting ears
are not
designed to support the weight of the R301 RF Power Supply. The user must
provide a shelf within the equipment rack to support the weight of R301. The user is
responsible for providing mounting hardware.
Note: the weight of the R301 RF Power Supply
is 43 pounds (19.5 kg)
Optional Mounting:
One (1) R301 RF Power Supply may be mounted in a 19” equipment rack with the use of
the optional single rack mount kit. The user must provide a shelf within the equipment
rack to support the weight of R301 unit.
Two (2) R301 RF Power Supplies in a 19” equipment rack with the use of the optional dual
rack mount kit. The user must provide a shelf within the equipment rack to support the
weight of two (2) R301 units.
Supplied Accessories:
Description Quantity Seren Part Number
½-Rack Mount Ear, 3U 2 4304870000
Power Cord (for 98-125V models) 14AWG,
IEC320-13 Receptacle to NEMA 5-15 Plug
* 4500910000
Power Cord (for 198-250V models) 14AWG,
IEC320-13 Receptacle to NEMA L6-15 Plug
* 4500910001
* Only 1 power cord is supplied with the R301 RF Power Supply. The power cord type
depends on the AC Mains voltage specified at time of order.
Connection to AC Mains:
BEFORE connecting the R301 RF Power Supply the AC mains, verify the AC Mains
voltage marked on the ratings plate, located on the top panel of the R301 RF Power Supply,
is compatible with your AC Mains voltage. If the AC Mains voltage on the ratings plate is
not compatible with your AC Mains voltage, contact a Seren IPS Inc. service depot and
arrange to have the mains voltage re-configured.
Note:
Incorrect AC Mains voltage may damage the R301 RF Power Supply. The AC
Mains voltage is not
field configurable.
Page 8
Seren IPS Inc.
6100130000 Rev. 0.05
