R301 RF POWER SUPPLY OPERATOR’S MANUAL

Basic Serial Interface Operation <SERIAL INTERFACE NOT IMPLEMENTED>

Refer to the Rear Panel Controls and Connections

section for serial interface connection

details. Serial commands are detailed in the Serial Commands

Section.

Serial interface protocol is RS-232, with 8 data bits, 1 stop bit, no parity. The baud rate is

selectable, 19200 Baud or 9600 Baud (see below). The factory default baud rate is 19,200

baud.

Connect the R301’s RF output to a 50-Ohm, 500 Watt resistive load, Impedance

Matching network, processing system or other suitable load before enabling AC

mains Power.

1. Connect a terminal, personal computer, or system controller to the rear panel SERIAL

interface connector.

2. Press the front panel POWER button (item 10) to enable mains power – the front panel

display will illuminate and momentarily display the firmware revision and copyright.

3. Select SERIAL control mode.

Note: The SERIAL control mode only needs to be selected once. The R301 RF power

supply will retain the selected control mode during a power-off/power-on cycle.

a. Press the PGM button (Item 1) once.

b. Press the DOWN button (item 2) or the UP button (item 3) until line 3 of the display

shows the current control source (PANEL CONTROL, ANALOG CONTROL, or

SERIAL CONTROL).

c. Press the VALUE UP button (item 5) or the VALUE DOWN button (item 6) until

SERIAL CONTROL is displayed on line 3.

d. Press the ENT button (item 5) to save the selection.

e. Remain in the programming environment, do not

press the RUN button.

4. Select the BAUD rate:

Serial control must be selected before attempting to select the baud rate. If the R301 is

set for PANEL or ANALOG control mode, the baud rate selection will not appear in the

programming menu.

Note: The BAUD rate only needs to be selected once. The R301 RF power supply will

retain the selected BAUD rate during a power-off/power-on cycle.

a. Press the DOWN button (item 2) or the UP button (item 3) until line 3 of the display

shows the current baud rate (19200 BAUD or 9600 BAUD).

b. Press the VALUE UP button (item 5) or the VALUE DOWN button (item 6) until the

desired baud rate is displayed on line 3

c. Press the ENT button (item 5) to save the selection.

Page 18

Seren IPS Inc.

6100130000 Rev. 0.05
