SEREN R301 - Programmable Parameter Details; Control Source Parameter Details

R301 RF POWER SUPPLY OPERATOR’S MANUAL
LEVEL PARAMETER DISPLAY LINE 3 OPTION
6 Output Power Range Select HIGH RANGE
LOW RANGE
0-300W Output*
0-30W Output
7 Exciter Mode (Frequency
Source) Select
EXCITER- MASTER
EXCITER- SLAVE
Internal Source*
External CEX Input
8 Maximum Output Power ENTER MAX POWER
XXXXW
1-300 Watts
(Default: 300 Watts)
9 Voltage Feedback Probe
Attenuation Factor
ENT PROBE ATTEN
XXXX
0 to 9999:1
(Default: 200:1)
10 Reflected Power Alarm REF PWR ALARM XXXW 1 to 300 Watts
(Default: 150 Watts)
11 Power Control Gain POWER CONT GAIN
XXX%
0% to 100%
(Default: 100%)
12 DC Voltage Control Gain DCV CONT GAIN XXX% 0% to 100%
(Default: 100)
13 Matching Network Preset Mode ENABLE MATCH PRE INV
ENABLE MATCH PRESET
DISABLE MATCH PRESET
ENABLE INVERTED
ENABLE
DISABLE*
14 Load Capacitor Preset Position LOAD PRESET XXX % 0% to 100%
(Default is 50%)
15 Tune Capacitor Preset Position TUNE PRESET XXX % 0% to 100%
(Default is 50%)
Page 28
Seren IPS Inc.
6100130000 Rev. 0.05
