User Manual SERVOPRO Plasma Trace N
2
Analyzer
6.0 INSTALLATION
17
1. TO AVOID DAMAGE TO ANALYZER, ALWAYS LEAVE THE
PROTECTION CAPS ON GAS CONNECTIONS UNTIL CLEAN GAS
IS READY TO FLOW IN THE ANALYSER.
2. THE VENT CONNECTION OF THE ANALYZER MUST BE AT
ATMOSPHERIC PRESSURE ALL THE TIME. PRESSURIZING
THE VENT SIDE OF ANALYZER COULD CAUSE THE QUARTZ
CELL TO CRACK AND ALSO DAMAGE THE FLOW MODULE.
FOR EXAMPLE, IF YOU HAVE TO CHECK YOUR SAMPLE LINES
FOR LEAKS, DON’T DO IT WITH THE ANALYZER CONNECTED
TO SAMPLE LINE WHILE THE VENT PROTECTION CAP IS STILL
INSTALLED. SO PLEASE DO YOUR LEAK TEST AND CONNECT
YOUR SAMPLE LINE TO SAMPLE INLET ONLY AFTER ALL
LEAK TESTS ARE DONE. ANY FAILURE TO FOLLOW THESE
RECOMMENDATIONS WILL VOID THE WARRANTY.
3. THE ANALYZER CABINET IS NOT DESIGNED TO BE
SUPPORTED BY FRONT PANEL ONLY. A BRACKET
SUPPORTING THE REAR OF THE ANALYZER CABINET MUST
BE INSTALLED. SEE USER MANUAL FOR DRAWING OF SUCH
INSTALLATION.
