7.0 OPERATION
If you have any options other than standard, you may also verify them (digital and/or fully
automatic calibration option). Please refer to the appropriate appendix of this manual.
FIGURE 8: DIAGNOSTIC MAIN MENU
In the diagnostic menu the cell counts and flow counts are displayed. It is very useful to verify
stability and cell offset.
By selecting "F2" it is possible to see the error and alarm historic menu.
“F3” brings you to the second diagnostic menu.
By pressing the "F2" key, it is possible to control the analog output manually. By selecting "F4:
RET", the system displays the DIAGNOSTIC MAIN MENU again. The display looks like the
following figure.
FIGURE 9: DIAGNOSTIC MENU
FIGURE 10: DIAGNOSTIC MENU
You need only enter any integer number value between 0 and 100 % and press the "E" key for
enter. Zero (0) is for 4 mA and one hundred (100) for 20 mA. This makes it easier to calibrate
<<DIAGNOSTIC MENU>> F3:NEXT
Cell counts: 13120
Flow counts: 1666432 Temperature: 24.45
F2:Error and Alarm historic F4:RET
<<DIAGNOSTIC MENU>>
Input value (0-100%):
<<DIAGNOSTIC MENU>> F3:NEXT
F2:4-20 mA output verification
