User Manual SERVOPRO Plasma Trace N
2
Analyzer
7.0 OPERATION
If you have to change the offset compensation factor, enter the value with the numeric keypad
and then, press E to validate the new value.
Press F2 to access the temperature gain menu.
FIGURE 17: TEMPERATURE GAIN
Minimum: 0
Maximum: 2
Resolution: 0.001
If you have to change the gain compensation factor, enter the value with the numeric keypad and
then, press E to validate the new value. The menu to enter the compensation factor for the offset
looks the same as the one for gain.
N.B: The ambient temperature is saved at each calibration. This value is compared with the
actual ambient temperature to calculate the new “compensated” ppm value.
<<<TEMPERATURE GAIN>>>
Gain :1.000
Actual:1.000
