Startup

Connection to the engineering software

Operating Instructions – MOVIDRIVE

modular

158

5.4.1 Check list for startup

The following checklist lists the necessary steps for complete startup.

Step Startup step Done

1 Motor installation

2 Install MOVI‑C

component

3 Start MOVISUITE

4 Start up the drive train

5 Parameterize setpoints and FCBs

6 Configure digital inputs and outputs

7 Configure PD

8 Configure software module (MOVIKIT

)

9 Test drives/application

5.5 Connection to the engineering software

The following figure shows the connection of the application inverter to the

MOVISUITE

engineering software using a PC.

[1]

RUN ERR

X15

X21 X20 X31

+UZ

-UZ

+UZ-UZ

24V

+UZ

-UZ

-UZ +UZ

GND

X31X20_1X21_1

X20_2X21_2

X15_1

X15_2

RUN ERR

+UZ

24V

GND

-UZ

+ UZ- UZ

X4 0

US 1

X8 5

L/ A

X8 0

L/ A

X4 1

L/ A

UHX 45 A- N

18014413831237515

[1] Ethernet

24748536/EN – 11/2017
