8.8 Technical data of encoder interfaces
8.8.1 Basic device
Terminal designation Specification
Encoder interfaces X15:1 – 15
Supported encoders
Resolver
SIN/COS
TTL/HTL
HIPERFACE
®
Encoders with RS422 signals
Connecting contacts 15-pin socket
Encoder supply
Nominal output voltage V
S24VG
DC 24V -10%, +20% according to EN61131
Nominal output voltage V
S12VG
DC 12V±10%
I
max
500mA
I
peak
for 150μs 1000 mA
Short-circuit protection of 12V supply Yes, but a permanent short circuit is not permitted.
Short-circuit protection of 24V supply Yes, but a permanent short circuit is not permitted.
8.8.2 CES11A multi-encoder card
Terminal designation Specification
Encoder interfaces X17:1 – 15
Supported encoders
SIN/COS
TTL/HTL
HIPERFACE
®
EnDat2.1
SSI
CANopen
Encoders with RS422 signals
Connecting contacts 15-pin socket
Encoder supply
Nominal output voltage V
S24VG
DC 24V -10%, +20% according to EN61131
Nominal output voltage V
S12VG
DC 12V±10%
I
max
500mA
I
peak
for 150μs 1000 mA
