Technical Data

Technical data for MDA and MDD axis modules

Operating Instructions – MOVIDRIVE

modular

219

8.4.5 Different functionality of the axis modules MDA/MDD

Functionality MDA90A-.. single-axis

module

MDD90A-..double-axis

module

Cam switch Yes -

Number of drive trains per output stage 2 1

Encoder option Yes -

I/O option Yes -

PWM frequency constant 2.5 kHz/4 kHz/8 kHz/16 kHz 4 kHz/8 kHz

PWM frequency 4kHz noise Yes -

Process data processing basic cycle 500 μs/1 ms/1ms PLC 1 ms

Simple encoder evaluation via digital in-

puts (DI04/DI05)

Yes -

Primary frequency input (DI04) Yes -

Sampling cycle n/X control 0.25 ms/0.5 ms/1 ms/2 ms 0.5 ms/1 ms/2 ms

24748536/EN – 11/2017
