6.5 Limit useful load combinations
Following table can be used as a simple load plan check. Useful
load within the ranges of single table line secures that the resultant
CG is within the limits approved for safe operation. Pilot is
responsible for ensuring, that the MTOW of 600 kg is not
exceeded.
Use only one row on
placard to read
allowed combination
of usefull load limits.
Example 1:
Pilot - 95 kg,
Passenger - 84 kg
– select table FLIGHT
WITH PASSENGER-
The ballast must be
placed in the front.
A maximum of 5 kg of
luggage may be
placed in the luggage
compartment.
Example 2:
Pilot - 100 kg
Baggage – 15 kg
Passenger maximum
weight is then limited
to 70 kg
