Shark 600 - Engine Instrument Markings

Section 2
Limitations
FLIGHT MANUAL
SHARK 600
2-6
Doc. No.: SHARK600_MA_075
2024-02-25
Rev. B
2.4 Engine Instrument Markings
The Shark 600 is in equipped with a Dynon SkyView or GARMIN
G3X Touch electronic flight display which displays flight
instruments and engine instruments. Other EFIS/EMS systems or
conventional engine instruments are optional.
Engine Limits
912 ULS
TACH - Max Engine Speed
5800 RPM
EGT - Exhaust Gas Temperature
880 °C
CHT - Cylinder Head Temperature
135 °C
OIL - Oil Temperature
130 °C
- Oil Pressure, max, cold start only
7 bar
100 PSI
- Oil Pressure, minimum below
3500 rpm
0.8 bar
12 PSI
- Oil Pressure, normal operation
2.0 – 5.0 bar
30 – 72 PSI
- Fuel Pressure: min-max
0.15 – 0.4 bar
2.2 – 5.8 PSI
ERT - Engine Room Temperature *
70 °C
TFUEL - Fuel Temperature *
70 °C
