7.4 Flight control system
Both occupants have access to a side-stick positioned on their right
armrest. Front rudder pedals are adjustable and equipped with
toe-brakes. Flaps and landing gear are operated by switches on
panel on pilot Instrument Panels, optionally on the rear panel. Trim
switches, radio buttons and autopilot switches are located on the
side-stick.
Elevator Control
The elevator is controlled by two sidesticks, hinged in a control
column through a system of push-pull rods and levers connected
directly to the two-piece elevator. The pushrod in the baggage
compartment is connected by cable and spring system to the flap
control system. This improve trimming on low speeds with flaps
and and it reduces the need for trimming when flaps are extended.
