7.8 Cockpit arrangement
• Access to the seats through a right-side hinged canopy. Enter
by stepping on the left wing
• Two composite height adjustable seats have adjustable
headrests and a four-point harness each
• Dual controls with two sidesticks on the right side, dual rudder
control pedals connected to the front wheel. Throttle, hydraulic
prop and choke lever are positioned on left panel, engine
cooling flap control panel in the front cockpit
• The main wheels are equipped with hydraulic brakes,
controlled by the toe brakes placed on the front pedals and
parking brake lever on the left side of the tunnel. The front
pedals are adjustable, pin controlling levers are on both sides of
the interior panel. A central brake lever for rear pilot is on the
left panel below the throttle a prop lever is optional
• 2+2 Air vents are placed on the sides of instrument panel.
• Flaps and landing gear control panel, electric propeller control
panel and radio panel are located on left side of the instrument
panel. If the propeller is hydraulic, a controlling lever for both
pilots is to the side of the throttle lever
• The right side of instrument panel is used for backup
instruments, GPS
• The middle panel is used for EFIS (Dynon SKYVIEW or GARMIN
G3X)
