Section 7
Airplane Description
FLIGHT MANUAL
SHARK 600
7-30
Doc. No.: SHARK600_MA_075
2024-02-23
Rev. C
• Below the EFIS screen there are switch/circuit breakers. The
autopilot panels and starter, magnetos and master switches are
below the breakers
• The trim switch, radio button and autopilot on/off buttons are
placed on top of the side-sticks
• A fuel selector valve is positioned in front of the left armrest
behind the throttle
• The fuel quantity indicator is shown on the EFIS/EMS display
• The ventilation and heating control knobs are located in the
front tip of the right armrest panel. Seat adjustment buttons
are located behind the side-sticks
• Red handles for emergency release of landing gear are located
in front of the front seat on the side panel and to the right side
of the middle tunnel
• Windows allowing to check properly locked gear struts with the
landing gear position indicators are situated on the root of
wings and on center panel
• A baggage compartment is situated behind the rear seat is
accessible from inside or from outside through a lockable door
• The Ballistic Recovery System has 2 independent RED activation
handles installed on the middle panel between pilot legs.
• Small storage compartments are provided beneath each
armrest
