Rear instrument panel
• The rear instrument panel is part of a canopy frame, optionally
equipped with EFIS/EMS screen connected to the main device
• The Instructor configuration option gives the rear pilot the
possibility to control flaps and landing gear from the rear
position. Engine start, magnetos and master switches are
located on the central panel. A single brake-lever activating
both main wheels is located on the left panel
• A slave radio control panel can be installed optionally
Cabin fire extinguisher (optional)
A portable fire extinguisher is installed on the side
wall of central tunnel under the pilot’s left leg. The
extinguisher is readily accessible in case of fire. The
extinguisher should be checked prior to each flight to
ensure that its bottle pressure, as indicated by the
gage on the bottle, is within the green arc and the
operating lever lock pin is securely in place.
