AL-1551CS DISASSEMBLY AND ASSEMBLY 8 - 14
3) Remove three screws and remove the single manual feed upper
frame.
4) Remove the PPD1 sensor PWB.
5) Remove the E-ring and remove the manual paper feed transport
roller.
6) Remove the cassette detection switch.
1)
2)
1)
3)
1)
2)
Wire treatment
3)
3)
4)
1)
2)
1)
2)
3)
Wire treatment
