AL-1551CS SIMULATION, TROUBLE CODES 10 - 2
2. List of simulations
Sim
No.
Kind of
main code
Sub
code
Operation
01 Optical system 01 Mirror scan operation
06 Aging of mirror scanning
02 SPF Individual
load operation
02 SPF sensor status display
03 Motor ON
04 Paper feed solenoid ON
05 Pressure release solenoid ON
(RSPF)
06 Resist clutch ON (RSPF)
07 Gate solenoid ON (RSPF)
05 Lamp ON
check
01 Operation panel display check
02 Fusing lamp, cooling fan operation
check
03 Copy lamp ON
06 Machine
individual load
operation
01 Paper feed solenoid ON
02 Resist solenoid ON
07 Aging 01 Warm-up display and aging with jam
06 Intermittent aging
08 High voltage
output check
01 Developing bias
02 Main charger (Grid high)
03 Grid voltage (Low)
06 Transfer charger
10 Other None Toner motor aging
14 Trouble reset None Cancel of troubles other than U2
16 U2 trouble
reset
None Cancel of U2 trouble
22 Counter
display
04 JAM total counter display
05 Total counter display
08 SPF counter display
12 Drum counter display
14 P-ROM version display
17 Copy counter display
18 Printer counter display
19 Scanner mode counter display
21 Scanner counter display
22 SPF JAM counter display
24 Special
counter clear
01 JAM total counter clear
04 SPF counter clear
07 Drum counter clear
08 Copy counter clear
09 Printer counter clear
13 Scanner counter clear
14 SPF JAM total counter clear
15 Scanner mode counter clear
25 Main motor
ON
01 Main motor operation check (Cooling
fan motor rotation check)
10 Polygon motor ON
26 Various setup 01 Manual feed setup
02 (R) SPF setup
03 Second cassette setup
04 Machine duplex setup
06 Destination setup
07 Machine conditions check
20 Rear edge void setup
30 CE mark support control ON/OFF
38 Cancel of stop at drum life over
39 Memory capacity check
40 Polygon motor OFF time setup
(Time required for turning OFF after
completion of printing)
42 Transfer ON timing control setup
43 Side void setup
44 SPF document rear edge read setup
62 Energy-save mode copy lamp setup
63 Fan control select setup
30 Sensor
operation
check
(Standard
provision)
01 Paper sensor status display
43 Fusing
temperature
setup
01 Fusing temperature setup (Normal
copy)
04 Fusing temperature setup 2
05 Fusing temperature setup in duplex
copy
09 Setup of fusing control of postcard
size paper
46 Exposure
adjustment
01 Copy density adjustment (300dpi)
02 Copy density adjustment (600dpi)
18 Image contrast adjustment (300dpi)
19 γ table setup or AE operation mode
setup
20 SPF exposure correction
29 Image contrast adjustment (600dpi)
31 Image sharpness adjustment
32 Copier color reproduction setup
48 Magnification
ratio correction
01 Front/rear (main scanning) direction
and scan (sub scanning) direction
magnification ratio adjustment
49 01 Flash ROM program writing mode
50 Lead edge
adjustment
01 Lead edge image position
10 Center offset adjustment
18 Memory reverse position adjustment
in duplex copy
19 Duplex copy rear edge void
adjustment
51 Timing
adjustment
02 Resist quantity adjustment
53 08 SPF scan position automatic
adjustment
61 Laser system
operation
03 Polygon motor check
(HSYNC output check)
63 Shading 01 Shading check
64 Self print 01 Self print
Sim
No.
Kind of
main code
Sub
code
Operation
