Sharp AL-1215 Service Manual

AL-1551CS SPECIFICATIONS 2 - 2
*1) May fluctuate due to environmental conditions and the input voltage.
Optical section Scanning
section
Scanning system 3 CCDs (RGB) sensor scanning by lighting white lamp
CCD sensor Resolution 600 dpi
Lighting lamp Type CCFL
Voltage 560Vrms
Power consumption 2.8W
Output data R, G, B 1 or 8 bits/pixel / A/D 16bit
Writing
section
Writing system Writing to OPC drum by the semiconductor laser
Laser unit Resolution 600 dpi
Image forming Photoconductor type OPC (30ø)
Life 18k
Charger Charging system Saw -tooth charging with a grid, / (-) scorotron
discharge
Transfer system (+) DC scorotron system
Separation system (-) DC scorotron system
Developing Developing system Dry, 2-component magnetic brush development system
Cleaning Cleaning system Counter blade system (Counter to rotation)
Fusing section Fusing system Heat roller system
Upper heat roller type Teflon roller
Lower heat roller type Silicon rubber roller
Heater lamp type Halogen lamp
Voltage 100V
Power consumption 800W
Electrical section Power source Voltage 100V, 110V, 120/127V, 230V, 240V
Frequency Common use for 50 and 60Hz
Power consumption Max. Less than 1000W
Average
(during copying)
AL-1215 300 Wh/H *1)
AL-1530CS 300 Wh/H *1)
AL-1540CS 300 Wh/H *1)
AL-1551CS 310 Wh/H *1)
Average (stand-by) ~ 127V 80Wh/H *1), 230V, 240V 75Wh/H *1)
Pre-heat mode ~ 127V 16.5Wh/H *1), 230V, 240V 18Wh/H *1)
Auto power shut-off mode ~ 127V 80Wh/H *1), 230V, 240V 75Wh/H *1)
