Sharp AL-2021 Service Manual

AL-2041 DISASSEMBLY AND ASSEMBLY 8 - 13
6. Manual paper feed section
A. List
B. Disassembly procedure
Multi unit
1) Remove the screw and remove the multi upper cover.
2) Remove the screw and remove the side door detection unit.
3) Remove three screws and remove the multi paper feed upper
frame.
4) Remove two screws and remove the multi feed bracket unit
from the multi paper feed upper frame.
No. Part name Ref.
1 Manual transport roller
2 Cassette detection switch
3 Side door detection unit
2)
1)
1)
2)
Back Wire treatment
1)
2)
1)
2)
2)
1)
1)
