Sharp AL-2030 Service Manual

AL-2040CS DISASSEMBLY AND ASSEMBLY 8 - 18
D. Set sensor, scan front sensor
1) Remove the set sensor.
2) Remove the scan front sensor.
3) Disconnect the connectors.
∗ When assembling, attach the blue harness to the marking B
side of the sensor, and attach the orange harness to the oppo-
site side sensor.
E. Transport roller
1) Remove the actuator.
2) Remove the transport roller.
3) Remove the gear and the bearing.
10. 2nd cassette section
Paper feed unit removal
1) Remove the screw.
2) Remove the rear cover.
∗ When installing, engage the pawl and install the unit.
1)
3)
2)
4)
1)
3)
3)
2)
B
3)
1)
2)
No. Part name Ref.
A Paper sensor
B Cassette detection SW
C Paper feed solenoid
D Transport roller
E Paper feed clutch
F 2nd paper feed roller
1)
1)
2)
2)
1)
1
2
A

Sharp AL-2030 Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	16 ppm
Copy speed (black, normal quality, A4)	20 cpm
Multi-Purpose tray	Yes
Total input capacity	250 sheets
Auto document feeder (ADF) input capacity	50 sheets
Power requirements	120 VAC +/- 10 %; 60 Hz +/- 2 %
All-in-one functions	Copy, Scan
Compatible operating systems	Windows 98, Me, 2000, XP, Vista
Market positioning	Business
