AL-2040CS SPECIFICATIONS 2 - 2
3. Copy performance
*1: The first-copy time is measured after the power save indicator turns off following power on, using the document glass with the polygon
rotating in the copy ready state and "Selection of copy start state" set to ON in the user programs (8-1/2" x 11" (A4), paper fed from
paper tray).
The first-copy time may vary depending on machine operating conditions and ambient conditions such as temperature.
Image forming Photoconductor Type OPC (30ø)
Life 18k
Charger Charging system Saw-tooth charging with a grid, / (-) scorotron
discharge
Transfer system (+) DC corotron system
Separation system (-) DC corotron system
Developing Developing system Dry, 2-component magnetic brush development
system
Cleaning Cleaning system Counter blade system (Counter to rotation)
Fusing section Fusing system Heat roller system
Upper heat roller Type Teflon roller
Lower heat roller Type Silicon rubber roller
Heater lamp Type Halogen lamp
Voltage 120V
Power consumption 800W
Electrical section Power source Voltage 120V
Frequency Common use for 50 and 60Hz
Power consumption Max. Less than 1000W
Average (during copying) 350Wh/H
Average (stand-by) 80Wh/H
Pre-heat mode 25Wh/H
Auto power shut-off mode 8.8W or less
Section, item Details AL-2030 AL-2040CS
Copy magnification Fixed
magnification
ratios
4 Reduction + 3 Enlargement
(AB system: 50, 70, 86, 100, 141, 200%)
(Inch system: 50, 64, 78, 100, 129, 200%)
Zooming
magnification
ratios
25 - 400% (376 steps in 1% increments)
50 - 200% when using SPF
Manual steps (manual, photo) 5 steps
Copy speed First-copy time *1
(Approximately)
8.0 seconds (When user program 24 is set to OFF)
10.7 seconds (When user program 24 is set to ON)
(paper: 8-1/2" x 11" (A4), exposure mode: AUTO, copy ratio: 100%)
Inch system
8-1/2" x 11"
(Landscape)
Copy speed
(CPM)
Same size 20 20
Enlargement 20 20
Reduction 20 20
AB system
A4 (Landscape)
Copy speed
(CPM)
Same size 20 20
Enlargement 20 20
Reduction 20 20
AB system
B5 (Landscape)
Copy speed
(CPM)
Same size 20 20
Enlargement 20 20
Reduction 20 20
Max. continuous copy quantity 99
Void Void area Leading edge 1 - 4mm
Trailing edge 4mm or less
Side edge
void area
0.5mm or more (per side)
4.5mm or less (total of both sides)
Image loss Leading edge same size: 3.0mm or less (OC) / 4mm or less (SPF/Duplex)
Enlarge: 1 - 5mm or less (OC) / 3mm or less (SPF/Duplex)
Reduction (50%): 6.0mm or less (OC) / 8mm or less (SPF/Duplex)
Warm-up time 0 sec. Immediately the ready lamp is lit.
Power save mode reset time 0 sec. Immediately the ready lamp is lit.
Paper jam recovery time 0 sec.
∗ Jam recovery condition: Recovery time from 60 sec of door open.
Section, item Details
