Sharp AN-37AG2 - Installing the wall-mount bracket (For Model 45 inch Separate Type)

E-6
Remove the table stand.
Remove the screws (4 screws) fastening the table stand, and then remove the table stand.
(Remove after pulling in the direction shown by the arrow.)
Save the removed stand fastening screws (4 screws).
Installing the wall-mount bracket (For Model 45 inch Separate Type)
1
Remove the terminal covers on the back of the LCD color TV.
• When installing the wall-mount bracket to the LCD color TV, place the LCD color TV face
down on a soft cloth or cushion.
• The stand can be removed while the LCD color TV standing upright, but Model 45 inch is
quite large, so for safety’s sake, the explanation of how to remove the stand is given with the
LCD color TV laying down.
Caution
2
Use the following procedures to install the Model 45 inch LCD color TV (LC-45GD1, LC-45GX6).
Soft cloth or cushion.
Stand fastening
screws (4 screws)
