E-13
ENGLISH
Installing the wall-mount bracket (For Model 37 inch Integrated Type) (Continued)
4
Install the wall-mount bracket.
Install the wall-mount bracket (with the angle set) to the back of the LCD color TV.
1
Align the wall-mount bracket screw holes (Marked I: 4 locations) to the LCD
color TV back holes.
2
Use the included M6 12mm length screws for TV installation B (4 screws) to
securely fasten the wall-mount bracket.
* When there are caps in the 4 holes on the back of the LCD color TV, remove
these ahead of time.
For TV installation B
Mark IMark I
Included part: Wall-mount bracket
Included part: M6 12mm length screws
(4 screws)
Included part: Wall-mount
brackt
