AR-M550/M620/M700 DETAILS OF EACH SECTION 6 - 21
Code
Signal
name
Name Function/Operation Type Model Note
M1LUD M1LUD Paper tray upper limit detector
(Paper feed tray 3)
Paper tray upper limit detection
(Paper feed tray 3)
Transmission
type
Paper feed tray system
sensor
M1PED M1PED Paper empty detector (Paper
feed tray 3)
Paper empty detection (Paper
feed tray 3)
Transmission
type
Paper feed tray system
sensor
M1PFD M1PFD Paper pass detector (Multi paper
feed tray 3)
Paper feed tray 3 paper pass
detection
Transmission
type
Paper transport system
sensor
M1PWS M1PWS Paper feed tray paper width
detector (Paper feed tray 3)
Multi paper feed tray paper width
detection (Paper feed tray 3)
Slide resistor Analog detector
M1SPD M1SPD Paper remaining quantity
detector (Paper feed tray 3)
Paper remaining quantity
detection (Multi paper feed tray 3)
Transmission
type
Paper feed tray remaining
quantity sensor
M2LUD M2LUD Paper tray upper limit detector
(Paper feed tray 4)
Paper tray upper limit detection
(Paper feed tray 4)
Transmission
type
Paper feed tray system
sensor
M2PED M2PED Paper empty detector (Paper
feed tray 4)
Paper empty detection (Paper
feed tray 4)
Transmission
type
Paper feed tray system
sensor
M2PFD M2PFD Paper pass detector (Multi paper
feed tray 4)
Paper feed tray 4 paper pass
detection
Transmission
type
Paper transport system
sensor
M2SPD M2SPD Paper remaining quantity
detector (Paper feed tray 4)
Paper remaining quantity
detection (Paper feed tray 4)
Transmission
type
Paper feed tray remaining
quantity sensor
M1PFC M1PFC Paper feed clutch (Paper feed
tray 3)
Paper freed tray 3 section roller
ON/OFF control
Electromagnetic
clutch
M2PFC M2PFC Paper feed clutch (Paper feed
tray 4)
Paper freed tray 4 section roller
ON/OFF control
Electromagnetic
clutch
DSKPFC1 DSKPFC1 Paper feed tray 3/4 paper
transport clutch 1
Paper feed tray 3/4 section paper
transport roller ON/OFF control
Electromagnetic
clutch
M1PUS M1PUS Paper pickup solenoid (Paper
feed tray 3)
Presses the paper pickup roller
onto paper.
Electromagnetic
solenoid
M2PUS M2PUS Paper pickup solenoid (Paper
feed tray 4)
Presses the paper pickup roller
onto paper.
Electromagnetic
solenoid
MM MM Main motor Drives the paper feed trays 1, 2, 3,
and 4, and the manual paper feed
section.
DC brushless
motor
Paper pass
M2SS PWB Paper size detection PWB Paper size detection
No. Name Function
1 Paper size detection plate Changes its own position in conjunction with the paper size (length) adjustment lever. By this
operation, the paper size detector detects the paper size.
2 Paper widht guide R Suppresses skew to the minimum by restricting the paper width.
3 Paper size detection rotation plate Changes its own position in conjunction with the paper size (length) adjustment lever. By this
operation, the paper size detection plate position is changed and the paper size detector detects
the paper size.
4 Paper size (length) guide plate Regulates the paper size (length).
5 Paper widht guide L By restricting the paper width, skew is restricted to the minimum.
6 Lift plate Lifts the paper to maintain the paper feed position at the fixed position.
7 Paper pickup roller Sends paper to the paper feed roller.
8 Separation roller Separate paper to prevent against double feed
9 Paper feed roller Feeds paper to the paper transport section.
10 Transport roller 8 (Paper feed tray 3)
Transport roller 5 (Paper feed tray 4)
Transports paper from the paper feed tray 3 to the transport rollers 9 and 10.
Transports paper from the paper feed tray 4 to the transport rollers 6 and 7.
11 Transport roller 10 (Paper feed tray 3)
Transport roller 7 (Paper feed tray 4)
Transports paper from the transport rollers 7 and 8 to the transport roller 11.
Transports paper from the transport roller 5 to the transport roller 10.
12 Torque limiter Provides a certain level of resistance power for the paper separation roller rotation to prevent
against double feed.
