INSTALLING THE SOFTWARE
48
Set the IP Address
This setting is only required once when using the machine on a network.
8
Click the "Set the IP Address"
button.
9
The printer or printers
connected to the network will
be detected. Click the printer
to be configured (the
machine) and click the "Next"
button.
10
Enter the IP address, subnet
mask, and default gateway.
The settings in the above window
are examples.
Be sure to ask your network
administrator for the correct IP
address, subnet mask, and default
gateway to be entered.
• The "Ethernet Address" is indicated on the left side of the machine
near the LAN connector.
• If the machine can not be recognized, enter the Ethernet Address
and click the "Initialize" button to initialize the IP address. Follow the
on-screen instructions to click the "OK" button and then the "Search"
button. If the machine is still not recognized, disable your computer's
firewall and then repeat the installation from the beginning.
When "Get IP Address Automatically" is selected, the IP address may at
times change automatically. This will prevent printing. In this event,
select "Assign IP Address" and enter the IP address.
Note
Note
!FO-2080.book 48 ページ ２００９年５月１５日 金曜日 午前１０時４２分
