MX-M753N AR-SU1 12 – 1
MX-M753N
Service Manual
[12] AR-SU1
1. Unpacking
A. Remove the stamp unit
B. Check the parts in the package
1) Check to confirm that all the parts are included in the package.
* When replacing the stamp cartridge, Refer to “Stamp cartridge
replacement” in the “User’s Guide” (PDF document) which is
stored in the hard disk of the machine. The user must be notified
of that. (Do not refer to “Stamp cartridge replacement procedure”
(package part No. 2).)
2. Installation
<Note before installation>
* Before execution of installation, check to confirm that the data
lamp on the installation panel is not on or blinking.
A. Turn off the power of the main unit
1) Turn OFF the power switch on the operation panel.
2) Open the front cabinet, and turn OFF the power switch.
3) Disconnect the power plug from the power outlet.
No. Part name Quantity
1Stamp unit 1
2 Stamp cartridge replacement procedure* 1
3 Stamp cartridge 3
4 Screw 1
