42
・The built-in inversion scan allows displaying videos in the upward direction, not in the conventional downward
direction. The image gaps between displays can be improved by arranging the inverted-scan displays under the
progressive-scan displays, achieving the natural moving image display.
・Set the inversion scan: [MENU] - [MONITOR] - [INVERSION SCAN] - [ON]
・ You can arrange the videos upside-down by setting [Inversion Scan] to [ON] when [PICTURE FLIP] is [ON] in
[MONITOR] of [MENU].
・This function is for professionals such as broadcasting stations.
It looks that the image is cut between the upper and the lower displays
when the bar is moved.
Progressive
Scan
The image looks to be bent, but, there is no image gap between the displays.
(It is not noticed unless the image is in portrait orientation.)
You need to set [PICTURE FLIP] to
[ON] or prepare a scan converter as
the image is turned upside-down in
the inversion scan mode.
Progressive
Scan
Progressive
Scan
Progressive
Scan
Progressive
Scan
Progressive
Scan
Inversion
scan
Inversion
scan
Conventional
Inversion scan
3.11.Inversion scan function
When setting the Inversion Scan,
do not set enlarge function or
cannot be connected in a daisy
chain. It won’t improve the image
gaps between displays.
