5.Soft switch description
• Soft switch
SW
NO.
DATA
NO.
ITEM
Switch Setting and Function
Initial
setting
Remarks
10
SW
|
A1
1 Protect from echo No Yes 0
2 Forced 4800bps reception Yes No 0
3 Footer print Yes No 1
4 Length limitation of copy/send/receive No limit Copy/Send: 1m Receive: 1.5m 0
5 CSI transmission No transmitted Transmitted 0
6 DIS receive acknowledgement during G3
transmission
Twice NSF: Once DIS: Twice 0
7 Non modulated carrier for V29
transmission mode
Yes No 1
8 EOL detect timer 25s 13s 0
SW
|
A2
Modem speed 9600BPS 7200BPS 4800BPS 2400BPS
1 No. 1 0 0 0 0 0
2 No. 2 0 0 0 0 0
3 No. 3 0 1 1 0 0
4 No. 4 1 1 0 0 1
5 Sender’s information transmit No Yes 0
6 H2 mode No Yes 0
7 Communication error treatment in RTN
sending mode (reception)
No communication error Communication error 1
8 CNG transmission No Yes 0
SW
|
A3
1 CED tone signal interval 1000ms 750ms 500ms 75ms
2 No. 1 1 1 0 0 0
No. 2 1 0 1 0 1
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
A4
1 Signal transmission level Binary input 16 8 4 2 1 0
2 No. = 12345 1
3 0 1 0 1 1 (-11dBm) 0
4 1
5 1
6 Protocol monitor (error print) Printed at com. err Not printed 0
7 Protocol monitor Yes No 0
8 Line monitor Yes No 0
SW
|
A5
1 Digital line equalization setting
(Reception)
7.2km 0km
2 No. 1 1 0 1
No. 2 1 0 1
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Error criterion 10 ~ 20% 5 ~ 10% 0
8 Anti junk fax check Yes No 0 OPTION
SW
|
A6
1 Auto gain control (MODEM) Enable Disable 1
2 End Buzzer Yes No 1
3 Disconnect the line when DIS is received
in Rx mode
No Yes 1
4 Equalizer freeze control (MODEM) On Off 0
5 Equalizer freeze control 7200 bps only No Yes 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
