Sharp UX-177 - Page 14

SW
NO.
DATA
NO.
ITEM
Switch Setting and Function
Initial
setting
Remarks
10
SW
|
B1
1 Recall interval Binary input 8 4 2 1 0
2 No. =12341
3 0101 0
4 (5 x 60 sec = 5 min) 1 OPTION
5 Recall times Binary input 8 4 2 1 0
6 No. =56780
7 0 0 1 0 (Twice) 1
8 0 OPTION
SW
|
B2
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
B3
1 PBX recall function (R key select) No Ope. No Ope. Earth Flash
2 No. 1 0 0 1 1 1
No. 2 0 1 0 1 1 OPTION
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Mercury line Yes No 1 OPTION
7 Reserved 0
8 Reserved 0
SW
|
B4
1 Reserved 0
2 Reserved 0
3 Dial mode Tone Pulse 1 OPTION
4 Pulse → Tone change function by key Enable Disable 1
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
B5
1 DTMF signal transmission level (Low) Binary input 16 8 4 2 1 1
2 No. = 12345 0
3 10100 (0.5 x 20 = -10 dBm) 1
4 0
5 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
|
B6
1 DTMF signal transmission level (High) Binary input 16 8 4 2 1 1
2 No. = 12345 0
3 10010 (0.5 x 18 = -9 dBm) 0
4 1
5 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
UX-177H
2 – 6
