2 Document guide lower ass’y
a. Remove the recording paper cover unit, the mechanism unit
according to procedure 1-a.
b. Remove the document guide upper ass’y and document guide
lower ass’y to the flowchart.
Parts list (Fig. 2)
No. Part name Q’ty No. Part name Q’ty
1 Under cabinet unit 1
8
Document guide lower
ass’y
1
2
Document guide upper
ass’y
1
9 Shaft 1
3 Screw (M3×10) 4
10
Paper feed roller gear
ass’y
1
4 Hook switch lever 1
5 Screw (M3×10) 1 11 Paper feed roller 1
6 Panel unit stopper 1 12 Cussion spacer 2
7 Connector 1 13 Document guide lower 1
3
4
5
6
7
8
9
10
11
13
12
1
13
9
11
8
12
12
1
7
4
3
3
5
6
2
3
3
10
2
Fig. 2
UX-177H
