Sharp UX-177 - Page 83

2 Upper cabinet
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
DCEKP333BXH01 BG N E Operation panel PWB unit
2
GCABA2269XHZE AQ N D Upper cabinet
3
HPNLH2371XHZK AL N D Decoration panel
4
JBTN-2107XHZA AG N C 12 key
5
JBTN-2175XHZA AG N C Direct key
6
JBTN-2176XHSA AE N C Start key
7
JBTN-2178XHSA AD N C Stop key
8
JBTN-2180XHZA AD N C Volume key
9
JBTN-2190XHZA AD N C Mode key
10
PGUMM2111XHZZ AD N C Rubber sheet
11
PSHEZ3214SCZZ AM N C Key sheet
(Unit)
901
CPNLH2371XH18 BM N D Upper cabinet ass’y
3 Document guide upper
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
LPLTG2707XHZZ AE C Rubber, separator
2
LPLTP2790XHZZ AD N C Separator plate
3
MLEVP2214XHZZ AC N C Document sensor lever
4
MLEVP2215XHZZ AF N C Panel lock lever
5
MSPRD2814XHZZ AC N C Sensor lever spring
6
MSPRP2812XHZZ AE N C Feed spring
7
MSPRT2813XHZZ AC N C Separate spring
8
MSPRT2815XHFJ AC N C Panel lock lever spring
9
NGERH2316XHZZ AC N C Idler gear
10
NGERH2317XHZZ AC N C Idler gear
11
NROLP2334XHZZ AE N C Pinch roller
12
NSFTZ2257XHZZ AG N C Pinch roller shaft
13
PGIDM2474XHZZ AF N C Document guide upper
14
PSHEZ3199XHZZ AD N C Face sheet
15
NGERH2305XHZZ AC N C Transfer gear
16
NBRGP2141XHZZ AH C Transfer bearing 2
17
NROLR2327XHZZ AQ N C Transfer roller 2
18
PSHEZ3239XHZZ AC N C Insulation sheet
UX-177H
– 4 –
