4 Drive unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
RMOTZ2126XHZZ AZ N B Motor
2
LFRM-2172XHZZ AM N C Drive system mounting frame
3
LPLTM2836XHZZ AE N C Heat sink
4
MCAMP2022XHZA AC N C Cam A
5
MLEVP2232XHZZ AD N C Planet gear lever A
6
MLEVP2233XHZZ AC N C Planet gear lever B
7
MLEVP2234XHZA AE N C Change lever
8
MSPRC2877XHZZ AC N C Planet gear spring
9
MSPRD2848XHZZ AC N C Change lever spring
10
NGERH2240XHZZ AC C Reduction gear A
11
NGERH2278XHZZ AC C Planet gear
12
NGERH2279XHZZ AC C Idler gear A
13
NGERH2328XHZZ AC N C Reduction gear B
14
QCNW-4588XHZZ AD N C Switch cable
15
QSW-F2224SCZZ AE C Detection switch
16
LPLTP2838XHZZ AH N C Planet gear plate
17
MSPRC2735XHZZ AC C Planet gear spring
18
NGERH2316XHZZ AC N C Idler gear B
19
NGERH2332XHZZ AC N C Reduction gear C
20
QCNW-4614XHZZ AD N C Cutter cam switch cable
21
PSHEZ3255SCZZ AD N C Anti vibration sheet
22
MSPRC2885XHZZ AC N C Cam spring
23
MSPRC2855XHZZ AC N C Planet gear spring
24
PSPAK2221XHZZ AC N C Cam spacer
5 Optical unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
DCEKD475AXH04 BC N E CCD PWB unit
2
LFRM-2164XHZA AN N C Optical frame
3
MSPRP2817XHZZ AC N C Lens holding spring
4
PGLSP2058XHZZ AE N C Reader glass
5
PLNS-2049XHZZ AZ N C Lens
6
PMIR-2070XHZZ AG N C Mirror 1
7
PMIR-2071XHZZ AH N C Mirror 2
8
PMIR-2072XHZZ AH N C Mirror 3
9
PSHEZ3196XHZZ AC N C Shading sheet
11
QCNW-4589XHZZ AD N C LED cable
12
VHPSNK15A24-1 AZ N B LED
13
PSHEZ3258XHZZ AC C Shield sheet 3
14
PFLT-2006XHZZ AA C Himelon sheet
15
PSHEZ3250SCZZ AC C Mirror sheet
(Unit)
901
DCYOD306BXH01 BU N E Optical unit
6 Packing material & Accessories
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
DUNTK307BXHAG AR N E Handset
2
QCNW-4494SCBK AF C Telephone line cord
3
QCNW-3976XHAG AH C Handset cord
4
SPAKA4868XHZL AF N D Side Add., left
5
SPAKA4868XHZR AF N D Side Add., right
6
SPAKA043AXHZZ AF N D Pad., AC cord
7
SPAKC007AXHZZ AF N D Packing case
8
SPAKP3385SCZZ AG N D Vinyl cover
9
SSAKA0003HCZZ AA N D Vinyl bag(240×360mm)
10
TINSE3665XHZZ AF N D Operation manual
11
TLABH3938XHZZ AD N D Repid key label
12
SPAKA042AXHZZ AF N D Protection pad.,,
13
PWIR-2023XHZZ AP N D Recording paper tray
14
PSHEZ3259XHZZ AC D Protection sheet
15
TLABZ2549XHZZ AD D Emergency label
16
SSAKA1340QCZZ AB D Vinyl bag
17
TCADZ2308XHZA AC D Service call label
18
TCADZ2309XHZA AC D After sales guide
19
TCADZ2310XHZZ AC D Warranty regi
20
QCNW-4266XHZZ AF C Extension telephone socket adaptor
UX-177H
– 6 –
