8 TEL-Liu PWB unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
147
VRS-TS2AD683J AA C Resistor(1/10W 68KΩ ±5%) [R136]
148
VRS-TS2AD332J AA C Resistor(1/10W 3.3KΩ ±5%) [R137]
149
VRS-TS2AD102J AA C Resistor(1/10W 1.0KΩ ±5%) [R138]
150
VRS-TS2AD122J AA C Resistor(1/10W 1.2KΩ ±5%) [R139]
151
VRS-TS2AD104J AA C Resistor(1/10W 100KΩ ±5%) [R140]
152
VRS-TS2AD104J AA C Resistor(1/10W 100KΩ ±5%) [R141]
153
VRS-TS2AD683J AA C Resistor(1/10W 68KΩ ±5%) [R142]
154
VRS-TS2AD124J AA C Resistor(1/10W 120KΩ ±5%) [R143]
155
VRS-TS2AD204J AA C Resistor(1/10W 200KΩ ±5%) [R144]
156
VRS-TS2AD204J AA C Resistor(1/10W 200KΩ ±5%) [R145]
157
VRS-TS2AD204J AA C Resistor(1/10W 200KΩ ±5%) [R146]
158
VRS-TS2AD102J AA C Resistor(1/10W 1.0KΩ ±5%) [R147]
159
VRS-TS2AD820J AA C Resistor(1/10W 82Ω ±5%) [R148]
160
VRS-TS2AD154J AA C Resistor(1/10W 150KΩ ±5%) [R149]
161
VRS-TS2AD104J AA C Resistor(1/10W 100KΩ ±5%) [R150]
162
VRS-TS2AD183J AA C Resistor(1/10W 18KΩ ±5%) [R151]
163
VRSTS2AD3651F AA C Resistor(1/10W 3.65KΩ ±1%) [R152]
164
VRS-TS2AD241J AA C Resistor(1/10W 240Ω ±5%) [R153]
165
VRS-TS2AD202J AA C Resistor(1/10W 2KΩ ±5%) [R154]
166
VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R155]
167
VRS-TS2AD561J AA C Resistor(1/10W 560Ω ±5%) [R156]
168
VRS-TS2AD162J AA C Resistor(1/10W 1.6KΩ ±5%) [R157]
169
VRS-TS2AD203J AA C Resistor(1/10W 20KΩ ±5%) [R158]
170
VRS-TS2AD203J AA C Resistor(1/10W 20KΩ ±5%) [R159]
171
VRS-TS2AD103J AA C Resistor(1/10W 10KΩ ±5%) [R160]
172
VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [R161]
173
VRS-TS2AD134J AA C Resistor(1/10W 130KΩ ±5%) [R162]
174
VRS-TS2AD471J AA C Resistor(1/10W 470Ω ±5%) [R163]
175
VRS-TS2AD183J AA C Resistor(1/10W 18KΩ ±5%) [R164]
176
VRS-TS2AD474J AA C Resistor(1/10W 470KΩ ±5%) [R165]
177
VRS-TS2AD204J AA C Resistor(1/10W 200KΩ ±5%) [R166]
178
VRS-TS2AD204J AA C Resistor(1/10W 200KΩ ±5%) [R167]
179
VRS-TS2AD102J AA C Resistor(1/10W 1.0KΩ ±5%) [R168]
180
VRS-TS2AD221J AA C Resistor(1/10W 220Ω ±5%) [R169]
181
VHD0R5G4B42-1 AF B Diode(0R5G4B42) [REC1]
182
QCNCW2468SC0C AB C Short pin socket [SOCKET]
183
QCNCM2467SC0C AB C Short pin(3pin) [SP1]
184
QSW-Z2214SCZZ AH B Hook switch(SPPY12-A) [SW1]
185
RTRNZ2140XHZZ AN B Transformer(Z2140) [T1]
186
RTRNI2142XHZZ AR B Transformer(I2142) [T2]
187
VHVTN07G101-1 AB B Varistor(TNR7G101KT2) [VA1]
188
RCRM-0091AFZZ AE B Crystal(3.58MHz) [X1]
189
VHEHZS3B1//-1 AC B Zener diode(HZS3B1) [ZD1]
190
VHEHZS3B1//-1 AC B Zener diode(HZS3B1) [ZD2]
191
VHEMTZJ300B-1 AA B Zener diode(MTZJ300B) [ZD3]
192
VHEMTZJ3R9B-1 AC B Zener diode(MTZJ3R9B) [ZD4]
193
VHEMTZJ3R9B-1 AC B Zener diode(MTZJ3R9B) [ZD5]
194
VHEHZ15-2//-1 AB B Zener diode(HZ15-2) [ZD6]
195
VHEHZ2A1///-1 AC B Zener diode(HZ2A1) [ZD7]
196
VHEHZ2A1///-1 AC B Zener diode(HZ2A1) [ZD8]
197
VHEHZ11C3//-1 AB B Zener diode(HZ11C3) [ZD9]
198
VHEMTZJ5R6B-1 AB B Zener diode(MTZJ5R6B) [ZD10]
199
VHEHZS3B1//-1 AC B Zener diode(HZS3B1) [ZD11]
200
VHEHZS3B1//-1 AC B Zener diode(HZS3B1) [ZD12]
201
VHEHZS3B1//-1 AC B Zener diode(HZS3B1) [ZD13]
202
VHEHZS3B1//-1 AC B Zener diode(HZS3B1) [ZD14]
203
VHEHZS3B1//-1 AC B Zener diode(HZS3B1) [ZD15]
204
VHEHZS3B1//-1 AC B Zener diode(HZS3B1) [ZD16]
205
VHEHZS3B1//-1 AC B Zener diode(HZS3B1) [ZD17]
206
VHEHZS3B1//-1 AC B Zener diode(HZS3B1) [ZD18]
(Unit)
901
DCEKL337BXH01 BK N E TEL-Liu PWB unit
9 Power supply PWB unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
0CB829650012/ BD B Transformer(PT-P88-KTT) [T1]
2
0CBUKZ0826ZZ/ AK B Filter(ELF15N003A) [L1]
3
0CBBFZ89154Z/ AC Ferrite core(BL01RN1-A62B1) [FB1]
4
0CBUAG0161CZ/ AP FET(FS5KM-18A) [Q1]
5
0CBUAC0027AZ/ AE B Transistor(2SC2655) [Q2]
6
0CBUAC0023AZ/ AD B Transistor(2SC1815) [Q3]
7
0CBUAC0056AZ/ AD B Transistor(2SC2002) [Q4]
8
0CBUCB0107AZ/ AQ B IC(NJM78M05FA) [IC1]
9
0CBUBC0215DK/ AD B Diode(RL1N4005-F) [D1, 2, 3, 4]
10
0CBUBC0248AZ/ AD B Diode(05NU42) [D5]
UX-177H
– 13 –
