Sharp UX-177 - Page 93

9 Power supply PWB unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
11
0CBUBA0003BK/ AD B Diode(1S2076A-TA) [D6, 9]
12
0CBUBB0216BZ/ AL B Diode stack(F6P20F) [D7]
13
0CBUBC0302AZ/ AE B Diode(SR140) [D8]
14
0CBUBDAC270B/ AC B Zener diode(RD27ESAB1) [ZD1]
15
0CBUBDAC3R3C/ AD Zener diode(RD3.3ESAB2) [ZD2]
16
0CBUBDAC6R2C/ AC B Zener diode(RD6.2ESAB2) [ZD3]
17
0CBUBDAE300D/ AD B Zener diode(RD30FB3) [ZD4]
18
0CBUEZ0507ZZ/ AD Varistor(ERZV07D471-CS) [V1]
19
0CBUDC0163BB/ AH B Photo coupler(PC123FY8) [PC1]
20
0CBUGZ0975ZZ/ AF C Film capacitor(2222 336 20104) [C1, 2]
21
0CBUGZ1072ZZ/ AN C Capacitor(KMF400VB68M 18X30) [C5]
22
0CBUGCU152BR/ AF N Ceramic capacitor(DE1105R152K1K-MHR) [C6]
23
0CBUGCU221BQ/ AD C Ceramic capacitor(DE0705-1R221K1K-MHR) [C7]
24
VCQYNU1HM472K AB Film capacitor(AMZ-472K50) [C8]
25
0CBUGFF683AR/ AD C Film capacitor(AMZ-683K50) [C9]
26
VCQYNU1HM102K AB C Film capacitor(AMZ-102K50) [C10, 11, 14]
27
0CBUGCM472AU/ AF N Ceramic capacitor(DE7100-1F472MVA1-H) [C12, 13]
28
0CBUGAE681UG/ AH C Capacitor(UPJ1V681MHH1AA) [C15]
29
0CBUGCS222AP/ AC C Ceramic capacitor(DD08-63E222P500) [C16]
30
0CBUGAC471UM/ AF C Capacitor(UPJ1C471MPH6AA) [C18]
31
0CBUGAC101HD/ AC C Capacitor(UVZ1C101MAH1AA) [C19]
32
0CBUGCM222BJ/ AF N Ceramic capacitor(DE1210-1E222M-KX) [C20]
33
0CBUEFC564BA/ AC C Metal film resistor(SFR25H560K(52)) [R1]
34
0CBUEFER33CH/ AC Metal film resistor(SPRX2R33J) [R2]
35
0CBUEEB153CT/ AC C Carbon resistor(RD16S-T26-153J) [R3]
36
0CBUEEB101CT/ AC C Carbon resistor(RD16S-T26-101J) [R4]
37
0CBUEEB564CT/ AC C Carbon resistor(RD16S-T26-564J) [R5, 6]
38
0CBUEFE104AV/ AD N Metal film resistor(RS2FS104J F-15) [R7]
39
0CBUEFE391CE/ AD Metal film resistor(RSS2 T52 391J) [R8]
40
0CBUEEC271BS/ AC N Carbon resistor(RDF50SS-T26-271J) [R9]
41
0CBUEEB330CW/ AC C Carbon resistor(RDF16S-T26-330J) [R10]
42
0CBUEEC122BS/ AC C Carbon resistor(RDF50SS-T26-122J) [R12]
43
0CBUEEB271CT/ AC C Carbon resistor(RD16S-T26-271J) [R13]
44
0CBUEEB682CT/ AC C Carbon resistor(RD16S-T26-682J) [R14]
45
0CBUEEB242CT/ AC C Carbon resistor(RD16S-T26-242J) [R15]
46
0CBUFBA501DH/ AC B Variable resisror(KVSF637T TB501) [VR1]
47
0CBPHZ0163ZZ/ AR N Relay(AJS33123(AJS1A-24V)) [RY1]
48
0CBUDZ0052ZZ/ AG B Thermistor(M16007C) [TH1]
49
0CBPJCTY1251/ AK A Current fuse(2151.25 ME600) [F1, 3]
50
0CBPZZ0602ZZ/ AC C Jumping wire(IPS-3002-2) [F2]
51
0CBSBD0508ZZ/ AC Label(D1043-6005C) [NP1]
53
0CBLRZ6251ZQ/ AP C Chassis(W4020-5001AT EZS) [MT1]
54
0CBLRZ6252ZP/ AP C Heat sink(W4020-5002AT TC) [MT2]
55
0CBLRZ6279ZP/ AP C Heat sink(W4023-5001AT TC) [MT3]
56
0CBPKZ0194ZZ/ AC C Base post ass’y(B 2P3-VH) [CN1]
57
0CBPCZ0211ZZ/ AG N Connector(09P-FJ) [CN2]
58
0CBUGCM102AT/ AE C Ceramic capacitor(DE7090-1B102KVA1-H) [C3, 4]
(Unit)
901
RDENT2102XHZZ BN N E Power supply PWB unit
10 CCD PWB unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C1]
2
VCKYPU1HF223Z AA C Capacitor(50WV 0.022µF) [C2]
3
QCNW-4593XHZZ AL N C Connector [CN1]
4
VHITCD1208GL1 AX B IC(TCD1208GL1) [IC1]
5
VS2SC1815GR-1 AB C Transistor(2SC1815GR) [Q1]
6
VRD-RC2EY222J AA C Resistor(1/4W 2.2KΩ ±5%) [R1]
7
VRD-RC2EY390J AA C Resistor(1/4W 39Ω ±5%) [R2]
(Unit)
901
DCEKD475AXH04 BC E CCD PWB unit
50 Hardware parts
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
XBPSD30P06K00 AA C Screw(M3×6K)
2
XEBSD30P16000 AA C Screw(M3×16)
5
XBPSN40P06K00 AA C Screw(M4×6K)
6
XEBSD30P06000 AA C Screw(M3×6)
7
XEBSD30P08000 AA C Screw(M3×8)
8
XEBSD30P10000 AA C Screw(M3×10)
