Sharp UX-41 Service Manual

FO-71RA
FO-51RA
1 Protect from echo No Yes 0
2 Forced 4800 BPS reception Yes No 0
3 Footer print Yes No 0
4 Length limitation of copy/send/receive No limit Copy/send: 60cm 0
Receive: 1.5m
5 CSI transmission No transmitted Transmitted 0
6 DIS receive acknowledgement during G3 Twice NSF: Once 0
transmission DIS: Twice
7 Nonmodulated carrier for V29 transmission Yes No 0
mode
8 Reserved 0
Modem speed V.29 V.27 ter
9600bps 7200bps 4800bps 2400bps
1 No. 1 0 0 0 0 0
2 No. 2 0 0 0 0 0
3 No. 3 0 1 1 0 0
4 No. 4 1 1 0 0 1
5 Reserved 0
6 H2 mode No Yes 0
7 Communication error treatment in RTN No communication error Communication error 0
sending mode (reception)
8 CNG transmission No Yes 0
CED tone signal interval 1000ms 750ms 500ms 75ms
1 No. 1 1 1 0 0 0
2 No. 2 1 0 1 0 0
3 MR coding No Yes 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
Signal transmission level Binary input
(0 ~ -31 dBm setting by 1 dBm step) No. = 16 8 4 2 1
1 1 2 3 4 5 0
2 0 1 1 0 0 (-12dB) 1
3 1
4 0
5 0
6 Protocol monitor (error print) Printed at com. error Not printed 0
7 Protocol monitor Yes No 0
8 Line monitor Yes No 0
Digital equalization setting (Reception) 7.2km 0km
1 No. 1 1 0 1
2 No. 2 1 0 1
Digital line equalization setting 7.2km 0km
3 (Transmitter) No. 3 1 0 0
4 No. 4 1 0 0
Digital equalization setting (Reception 7.2km 0km
5 for Caller ID) No. 5 1 0 0
6 No. 6 1 0 0
7 Error criterion 10 ~ 20 % 5 ~ 10 % 0
8 Anti junk fax check Yes No 1
2 – 5
Switch setting and function
5. Soft switch description
• Soft switch
SW
NO.
DATA
NO.
ITEM
1
0
Remarks
Initial setting
SW
l
A1
SW
l
A2
SW
l
A3
SW
l
A5
SW
l
A4
RA
