Sharp UX-41 Service Manual

FO-71RA
FO-51RA
Fig. 8
3 – 10
Parts list (Fig. 8)
PO roller guide and head frame unit
8
2
3
4
5
1
6
13
13
14
14
12
2
3
4
5
1
7
8
9
6
12
13
11
10
Control
PWB
Hook
11
9
7
8
10
14
7 PO roller ass’y (FO-71 only) 1
8 PO roller guide (FO-71 only) 1
9 Screw (3×10) 1
10 Earth plate 1
11 Head earth cable 1
12 Head frame unit 1
13 Screw (3×8) 2
14 Panel lock lever spring 2
No. Part name Q’ty No. Part name Q’ty
1 Mechanism unit 1
2 Screw (3×6) 1
3 Connector 1
4 Screw (3×8) 1
(FO-71 only)
5
PO roller guide unit 1
(FO-71 only)
6 PO gear (FO-71 only) 1
